Dejavoo Z11 Technical Specifications
Processor & Memory
- Processor: 32-bit 400MHz Secure Microprocessor
- Memory: 128MB Flash / 64MB DDR RAM
- Micro SD Socket: Optional
Display & Input
- 3.5″ Color LCD Touchscreen (320 x 480 pixels)
- Keypad: 15 standard keys
Card Reader Capabilities
- Magnetic Stripe: ISO 7810, 7811, 7813 (Triple Track, Bi-Directional)
- Contact Card: ISO 7816 ID-1, 1.8V/3V/5V T=0, T=1
- Contactless: ISO 14443 Type A/B, ISO 18092 NFC, MIFARE, SONY Felica
Communications
- Ethernet & Dial-Up Modem
- 2 x RS232, 2 x USB
- WiFi (Optional)
Security & Compliance
- Crypto: TRNG, DES, TDES, AES, RSA, MK/SK, DUKPT, T-DES DUKPT
- Certifications: PCI PTS, EMV L1 & L2, TQM, PBOC L1 & L2
- Payment Support: Visa PayWave, MasterCard PayPass, American Express, JCB J/Speedy
- Safety: CE, FCC, BSMI, RoHS
Printer
- Graphical Printer: 57mm, 4″ per second
- Paper Roll: 2.25″ x 80′
Physical Specifications
- Dimensions: 7.5 (L) x 3 (W) x 3 (H) in
- Weight: 0.77 lbs
Environmental
- Operating Temperature: 32°F to 150°F
- Storage Temperature: -4°F to 158°F
