Valor VL500 Technical Specifications
Processor & Memory
- Processor: Quad-Core 32-bit Processor + Secure MCU
- Memory: 8GB Flash / 1GB RAM
- MicroSD Socket: Yes
- Operating System: Android 7.1.2
Display & Input
- Display: 5.5” Color TFT Capacitive Touch Display
- Resolution: 1280 x 720 pixels
- Keypad: Virtual Touch PIN Entry
Card Reader Capabilities
- Magnetic Stripe: ISO 7810/7811/7813, Triple Track
- Smart Card: ISO 7816 ID-1, 1.8V/3V/5V, T=0 & T=1
- Contactless: ISO 14443 A/B, ISO 18092 NFC, Mifare, Sony FeliCa
Camera & Audio
- Rear Camera: 5MP Autofocus with Flash
- Front Camera: 2MP Fixed Focus
- Audio: Speaker, Microphone, 4-Pole Audio Jack
Printer
- Thermal Printer: 57mm x 40mm paper size
- Print Speed: 100mm/sec
Communication & Connectivity
- Wireless: 4G LTE / 3G / GPRS / WLAN / Bluetooth
- GPS: Yes
- SIM Cards: Dual SIM Support
Power & Battery
- Power Supply: 5V / 2A
- Battery: 6000mAh / 3.7V Li-ion Rechargeable
Docking Station
- Charging
- Ethernet & Wi-Fi Access Point
- Ports: 1 x USB-A, 1 x RS232
Environmental
- Operating Temperature: -10°C to 70°C
- Storage Temperature: -20°C to 70°C
- Humidity: 5% to 90% Non-condensing
Certifications
- PCI PTS 6.x, EMV L1/L2
- Visa payWave, Mastercard PayPass, Amex ExpressPay
- Discover D-PAS, Interac Flash, J-Speedy, UnionPay UICS
- TQM, PBOC L1/L2
