Valor VP550E Technical Specifications
Processor & Memory
- Processor: Cortex Quad-core A53, 2.0GHz
- Security Processor: Cortex-M3
- Operating System: Android 12
- Memory: 16GB Flash / 2GB RAM
- Micro-SD Socket: Up to 256GB
Display & Input
- 5″ TFT Full Color LCD Display (1280 x 720)
- Capacitive Multi-Touch, Electronic Signature Support
- Secure Virtual Keypad
- Buttons: Power + 2 Function Buttons
Card Readers
- Magnetic Stripe: Triple Track, Bi-directional (ISO 7810/7811/7813)
- Smart Card: EMV L1/L2, ISO 7816, T=0 & T=1, 1.8V/3V/5V
- Contactless: Under-screen solution, ISO 14443 A/B, Mifare, Felica
Connectivity & Ports
- Wireless: 4G / 3G / 2G, Wi-Fi (802.11 a/b/g/n) 2.4G & 5G, Bluetooth 5.0
- Positioning: GPS / GLONASS / BEIDOU
- Peripheral Port: 1 x Type-C (OTG)
- Card Slots: 1 x SIM, 1 x SAM
Camera
- Front Camera: 0.3MP (Supports 1D/2D Code Payment)
- Rear Camera: 5MP Autofocus with Flash (Supports 1D/2D Code Payment)
Audio & Battery
- Speaker & Microphone: Audio Recording & Playback
- Battery: Li-ion 3.8V / 3600mAh / 13.68Wh
- Power Supply: Input 100-240V AC, Output 5V DC / 2.0A
Physical & Environmental
- Dimensions: 150L x 74W x 16.8H mm (18.8mm at swipe section)
- Weight: 245g (with battery)
- Operating Temp: 10°C to 50°C
- Storage Temp: -20°C to 60°C
- Humidity: 5% to 93% (non-condensing)
Certifications
- PCI PTS 6.x, EMV L1/L2, EMV Contactless L1
- PayPass, payWave, American ExpressPay, Discover D-PAS
- UnionPay QuickPass, JCB, CE, RoHS, FCC, TQM, CB, Felica
